AWUS036AXML is a WiFi 6 high-performance USB adapter. It works in three frequency bands 2.4 GHz / 5 GHz/ 6 GHz on a 802.11ax standard using 2×2 MIMO technology. It also supports Bluetooth v5.2. The data transfer rate reaches up to 1800 Mbps. The USB adapter comes with a 2-in-1 USB-C / USB-A cable, so if your laptop or PC doesn’t have USB Type C, it could also use a USB Type A. The RP-SMA antenna connectors allow connecting the antennas with higher gain to increase the connection distance.
Key features:
- WiFi 6 (802.11ax)
- Tri-band 2.4 GHz / 5 GHz / 6 GHz
- Bluetooth 5.2
- Detachable antenna
- Robust USB Type-C
- High-speed wireless 1800 Mbps
- Included screen clip
- Included 2-in-1 (USB-C/USB-A) power + data USB cable
מפרט טכני:
| Wireless Network |
|---|
| Generation | WiFi 6 |
| Standards | 802.11n/ac/ax |
| MIMO | 2.4GHz 2×2, 5GHz 2×2, 6GHz 2×2 |
| Frequency | 2.4GHz, 5GHz, 6GHz |
| 2.4GHz Radio Rate | 300 Mbps |
| 5GHz Radio Rate | 867 Mbps |
| 6GHz Radio Rate | 573.5 Mbps, 1200 Mbps |
| Antenna |
|---|
| Antenna Design | Omni |
| Wireless Antenna Frequency Range & Gain | 2.412 – 2.483 (GHz) (dBi), 5.1 – 5.9 (GHz) (dBi), 5.925 – 7.125 (GHz) (dBi) |
| Connectors |
|---|
| RF Connectors | (2) RP-SMA Female |
| Interfaces |
|---|
| USB Ports | (1) USB Type C |
| Bluetooth | 5.2 |
| System Specification |
|---|
| Chipset | MediaTek MT7921AUN |
| Physical Parameters |
|---|
| Color | Black |
| Material | Plastic |
| Dimensions | 85 x 63 x 20 mm |
| Weight | 0.07 kg |
| Operating Temperature | -25 °C to 75 °C |
| Environment | Indoor |
| Mounting Method | Personal Holder, Tabletop |
| Form Factor | Desktop |
