ATL LTE18 kit is Mikrotik’s new LTE solution for connectivity in rural and urban areas. It’s designed to provide fast and stable internet, regardless of your phone signal or the weather. ATL features a Category 18 LTE modem and a Gigabit Ethernet port with PoE-in – in combination with the ARM CPU, it allows the speed up to 1 Gbps.
One of the main features of the ATL LTE18 kit is the 4×4 MIMO (multiple-input, multiple-output support). Higher speed and better signal are provided by 4 high-gain middle bands (1.7 – 2.7 GHz) and 2 high-gain low band antennas (700 MHz – 1 GHz, LTE Band 28). Since most mobile operators in the world use the 700 and 800 MHz LTE, and, considering that the lower frequency can travel further – ATL will always be able to find some signal.
The device is designed resistant to snow and water, which will prevent it from collecting water or freezing in low temperatures. It will be an amazing fit for cold cities and rural areas with rough weather conditions, the ATL LTE18 kit will function perfectly even without cleaning the antenna. It’s also ensured that ATL will serve you for a long time, as the upgrades will not be necessary for the near future.
מפרט טכני:
| Mobile Network |
|---|
| Mobile Network Generation | 3G (UMTS), 4G (LTE) |
| LTE Category | Cat18 – 1.2Gbps/150Mbps |
| FDD LTE Frequency Bands | 1 (2100MHz), 3 (1800MHz), 5 (850MHz), 7 (2600MHz), 8 (900MHz), 20 (800MHz), 28 (700MHz) |
| TDD LTE Frequency Bands | 38 (2600MHz), 40 (2300MHz), 41 (2500MHz) |
| SIM Card Slot | Micro-SIM |
| Antenna |
|---|
| Antenna Design | Parabolic Dish |
| Interfaces |
|---|
| RJ45 Ports | (1) 1 Gbps |
| Management | Ethernet |
| PCI Express | (1) M.2 PCIe Slot |
| System Specification |
|---|
| Chipset | Dual-core 88F3720 1.2 GHz |
| RAM | 256 MB |
| Storage Memory | 16 MB |
| Power |
|---|
| Power Method | 802.3af PoE, 802.3at PoE+ |
| Power Supply | External AC/DC Adapter |
| Supported Input Voltage | 12 – 57 V DC |
| Max Power Consumption | 8 W |
| PSU / POE adapter | 24 V DC 0.8 A |
| Physical Parameters |
|---|
| Ingress Protection Code | IP54 |
| Dimensions | 315 x 315 x 170 mm |
| Operating Temperature | -40 °C to 70 °C |
| Environment | Outdoor |
| Mounting Method | Pole Mount |
| Package Contains |
|---|
| External Power Supply | Included |
| Software |
|---|
| MikroTik | RouterOS Level 3 |
